Consult for options available.

Fuel reservoir : 70 gal. (265 L). Hydraulic oil reservoir : 89 gal. (337 L).

Type : Electronic-over-hydraulic. Controls : GOMACO’s exclusive G+^® control system for paving accuracy and ease of operation. It features multi-language, metric or imperial settings, and a 6.5 in. (165 mm) anti-glare display screen. Control indicators : Color graphical performance indicators allow operator to monitor control signals for machine guidance on stringline or 3D.

Type : On-board water system. Capacity : One 100 gal. (379 L) high-pressure water tank with trigger gun control and adjustable pressure unloader for up to 2000 psi.

Curb and gutter mold : One curb and gutter mold. Optional molds available for curb and gutter, barrier, parapet, and sidewalk.

Type : Hydraulically powered, motor-in-head, variable speed, independently controlled, and synchronized with machine movement. Quantity : Two vibrators and four circuits are standard.

Hydraulic lift : 18 in. (457 mm) pressure-compensated hydraulic vertical adjustment with 26 in. (660 mm) manual vertical adjustment. Sideshift : 36 in. (914 mm) maximum hydraulic sideshift.

Direct-drive trimmerhead : Trimmerhead is directly driven with a radial piston hydraulic motor which provides maximum torque for trimming capacity. 24 in. (610 mm) diameter trimming wheel. Trimmer wheel rotation : Upward cut. Width : 30 in. (762 mm) to 66 in. (1676 mm) sectionalized trimmerhead with hydraulic sideshift capability. Sideshift distance : 48 in. (1219 mm) maximum hydraulic sideshift. Hydraulic lift trimmer : 18 in. (457 mm) hydraulic vertical adjustment, with 6 in. (152 mm) manual vertical adjustment.

Drive : Direct drive via radial piston hydraulic motor. Length : 17 ft. (5.18 m). Auger diameter : 16 in. (406 mm). Auger speed : Variable up to 88 rpm. Auger mount : Features 42 in. (1067 mm) hydraulic slide adjustment and hydraulic pivoting mount (slide and tilt) for negotiating discharge from the ready-mix truck and negotiating grade variations. Wear surface : Features replaceable auger flight liners.

Type : Hydraulically powered, reversible with charging hopper. Pivot mount conveyor with hydraulic lift and positioning. Length : 20 ft. (6.1 m) folding conveyor with hydraulic lift, shift, and pivot. Width : 24 in. (610 mm). Belt speed : Variable up to 254 fpm (77.4 mpm). Belt wiper : Features special blades on adjustable spring steel rods for superior cleaning results. The unique, no-maintenance troughing rollers are greaseless and self-cleaning. Conveyor mount : Features 42 in. (1067 mm) hydraulic slide adjustment and hydraulic pivoting mount (slide and tilt) for negotiating discharge from the ready-mix truck and negotiating grade variations. Hopper : Designed for more concrete capacity to allow slipforming a complete radius without waiting for concrete delivery.

Type : Three hydraulically powered, gear-driven crawler tracks. Overall track length : 5.1 ft. (1.6 m). Track pad width : 11.8 in. (300 mm). Track speed : Variable up to 49.5 fpm (15.1 mpm); auxiliary variable up to 131 fpm (39.93 mpm). Leg height adjustment : Each track has 36 in. (914 mm) hydraulic adjustment and an additional manual adjustment of 8 in. (203 mm). Front legs : The two front legs are mounted on parallelogram-style pivot arms. Power-slide leg for positioning rear track : Hydraulically controlled, allows up to 5.9 feet (1.8 m) lateral track movement.

Overall length with folded conveyor : 25.1 ft. (7.65 m). Overall length with unfolded conveyor : 31 ft. (9.45 m). Overall length without conveyor : 22.3 ft. (6.8 m). Overall length with auger : 28.7 ft. (8.75 m). Overall height : 9.1 ft. (2.77 m). Overall width : 8.3 ft. (2.53 m).

28,000 lbs. (12,701 kg). Weight can vary depending on size of mold and options. Note : Transport and operational weights and dimensions are variable, depending on machine options.

One additional 100 gal. (379 L) water tank. Guillotine-style curb depressor has a straight blade that enters the face of the curb. Hydraulically powered, for use on curb and gutter molds while slipforming through driveways. Can be changed to other molds if they are slotted and clamped to accept the driveway cutout. California-style curb depressor has a curved blade that enters the face of the curb. Hydraulically powered, for use on curb and gutter molds while slipforming through driveways. Hydraulic pressure-compensated sideplates. Additional vibrators and mounts. Additional vibrator circuits and controls. Left-hand or right-hand discharge trimmerhead. Trimmerhead insert sections of 12 in. (305 mm), 18 in. (457 mm), 24 in. (610 mm), and 30 in. (762 mm) widths are available for trimmerhead width up to 66 in. (1676 mm) maximum. Additional molds built to customer specifications. Various mold options are available. Polyurethane track pads, 81 pads required. Radius wheels for use on radius work, saving time on stringline set-up. 3D package for machine guidance. GOMACO Remote Diagnostics (GRD) available. Other options are available to customize the machine to accommodate applications and customer needs.
