Type : Cummins diesel. Horsepower : 70 hp (52.2 kW) @ 2100 rpm.

Fuel reservoir : 33 gal. (124.9 L). Hydraulic oil : 57 gal. (215.8 L).

Pump : One dual stage main pump provides 30 gpm (113.6 Lpm) @ 2100 rpm. Hydraulic oil cooling : One air-to-oil cooler. Filtration : One 10-micron, return line filter.

Width : 24 in. (610 mm) belt. Belt speed : 528 fpm (160.93 mpm). Belt rollers : 20 degree, tapered roller cones support upper belt. Diverter car discharge : Front or rear. Diverter car speed : Up to 131 fpm (39.93 mpm).

Traction speed : Up to 38 fpm (11.58 m) forward or reverse with standard bogies. Traction drive : Hydraulically powered, two double-flanged, 8.6 in. (218 mm) diameter, steel trolley wheels, skewable.

Frame : Lattice-type, structural angle-iron with pin-connected sections interchangeable in 12 ft. (3.66 m), 6 ft. (1.83 m) and 3 ft. (.91 m) sections.

24 in. (610 mm) frame depth for spans up to 75 ft. (22.86 m). 32 in. (813 mm) frame depth for spans up to 135 ft. (41.15 m).

Frame to bogie per customer specifications.

27 ft. (8.23 m) unit : 7,318 lbs. (3,319 kg). 12 ft. (3.66 m) extension : 900 lbs. (408 kg). 6 ft. (1.83 m) extension : 465 lbs. (211 kg). 3 ft. (.91 m) extension : 260 lbs. (118 kg).

27 ft. (8.23 m) unit : 7,638 lbs. (3,465 kg). 12 ft. (3.66 m) extension : 945 lbs. (429 kg). 6 ft. (1.83 m) extension : 488 lbs. (221 kg). 3 ft. (.91 m) extension : 273 lbs. (124 kg).

70 hp (52.2 kW) CAT diesel engine. Two 4-wheel end cars, flanged flat or cupped wheels. 6 in. (152 mm) and 12 in. (305 mm) frame elevators. Transport assembly with transport axle, 6.7 in. (170 mm) by 15 in. (381 mm) 6-ply tires and towing tongue for job site use only. Crawler tracks, 11 ft. 7 in. (3.53 m) long, hydraulically driven with 11.8 in. (300 mm) wide pads with street grousers. 36:1 gear reduction. Rubber tired bogies, hydraulically driven, foam-filled flotation tires, 26 in. (660 mm) diameter by 12 in. (305 mm) wide. Telescoping tremie. Slope wedges. Other options are available to customize machine to accommodate applications and customer needs.
