Type : CAT diesel, four cylinder, four stroke. Power : 83 hp (61.92 kW) @ 2200 rpm. Displacement : 269 cid (4.41 L).

Fuel reservoir : 33 gal. (124.9 L). Hydraulic oil reservoir : 57 gal. (215.8 L).

Self-contained : Hydraulic console with easy-to-operate controls. Automated control system: Automated grade and steering control system. Type : Electronic-over-hydraulic.

CF-790 traction drive : Two gear-driven crawler tracks, hydraulically powered, 11 ft. 8 in. (3.56 m) long; center-to-center sprocket/idler length, 9 ft. 11 in. (3.02 m). Track pad width : 15.75 in. (400 mm). Operating speed : Variable up to 16.7 fpm (5.09 mpm) while paving and travel speed is variable up to 50.44 fpm (15.37 mpm).

Frame construction : All-welded steel, pin-connected main frame. Width : Up to 72 ft. (21.95 m). (Note: Consult factory with your specific job requirements.)

Finishing cylinder : Two 10 in. (254 mm) diameter, 48 in. (1219 mm) long. Cylinder rotation : 320 rpm. Carriage speed : Variable to 42.6 fpm (12.98 mpm). Augers : One 10 in. (254 mm) diameter (right-hand) and one 10 in. (254 mm) diameter (left-hand) with auger guard. Finishing pan : 25 in. (635 mm) x 22 in. (559 mm) trailing float pan.

49 ft. (14.94 m) unit : 42,900 lbs. (19,459.4 kg). 72 ft. (21.9 m) unit : 47,476 lbs. (21,535.1 kg).

Adjustable 10 in. (254 mm) diameter cylinders and adjustable double-wrap 7.75 in. (197 mm) diameter by 24 in. (610 mm) long augers with a 3 in. (76 mm) pitch. Augers can be quickly adjusted to 1 in. (25mm) above or below the finishing cylinder. Trimmer undercarriage assembly. Single-cylinder undercarriage with 60 in. (152.4 mm) long cylinder and external vibration. Up to 700 vpm. Additional emergency stop buttons available. One set of slipform assemblies, depth to customer specifications. One or two lines of Spanit® work bridge, 1000 series Spanit® used as crosswalks and for hand finishing, as required. Other options are available to customize machine to accommodate applications and customer needs.
