Type : KDW 1404 Kohler Diesel engine, water cooled. Emission Level : Tier 4 Final. Power : 24 hp (17.9 kW) continuous @ 2700 rpm.

Fuel reservoir : 11 gal. (41.64 L). Hydraulic oil reservoir : 13.5 gal. (51.1L).

Type : Hydraulic with controls located on the handle. The manual travel control valve, manual three-point grade control, cross auger directional controls, engine controls, vibrator control knob, cross-auger speed control knob, and E-stop warning light are located on the handle.

Type : Hydraulically powered, motor-in-head, variable speed, independently controlled. Recommended when slipforming over vertical dowels or inserting longitudinal steel.

Concrete : 19 cu. ft. (0.54 cu. m). Asphalt : 7.1 cu. ft. (0.2 cu. m).

Adjustable : 15 in. (381 mm) sliding hopper. Auger dimensions : 12 in. (305 mm) diameter by 5.5 ft. (1.68 m) long for concrete. Auger drive : Hydraulic motor direct coupled to auger shaft. Auger speed : Up to 43 rpm.

Asphalt extrusion kit includes a double skin hopper and auger, heavy duty extruding auger and drive, propane burner and propane tank.

Track dimensions : One track, 23 in. (584 mm) long, 8 in. (203 mm) wide, by 9 in. (229 mm) high. Track motor : 22.6 cid roller vane motor. Equipped with a track brake system. Wheel assemblies : Eight - 9 in. (229 mm) diameter by 3 in. (76 mm) wide wheels. Travel speed : Up to 40 fpm (12.2 mpm) paving, 93 fpm (28.3 mpm) auxiliary. Track load : 1225 lbs. (555.7 kg). Ground Pressure at 22 psi. Wheel load : 1275 lbs. (578.3 kg) with weight equally distributed on eight wheels.

24 inches (610 mm) depending on mold profile.

Overall transport dimensions : 9.1 ft. (2.77 m) long with the handle in vertical position, 7.3 ft. (2.23 m) wide, and 3.5 ft. (1.07 m) high to the top of the shroud.

3419 lbs. (1551 kg).

Track dimensions : 23 in. (584 mm) long, 8 in. (203 mm) wide, by 9 in. (229 mm) high. Track motor : 22.6 cid roller vane motor. Travel speed : Up to 20 fpm (6.1 mpm) paving, 93 fpm (28.3 mpm) auxiliary. Track load (rear) : 1225 lbs. (555.7 kg). Ground pressure at 22 psi. Track load (front) : 1275 lbs. (578.3 kg.), with weight evenly distributed on both tracks, ground pressure at 12 psi. Optional three-track overall dimensions : 9.5 ft. (2.9 m) long, 6.6 ft. (2.01 m) wide, and 3.5 ft. (1.07 m) high.
