Type : 48-volt DC lithium-ion battery pack for a full paving day.

Hydraulic oil reservoir : 13.5 gal. (51.1L).

Type : Radio Remote Control with G+ control system. Remote features manual travel control, manual three-point grade control, cross auger directional and speed controls, engine controls, vibrator control and E-stop.

Type : One variable speed electric vibrator.

Concrete : 19 cu. ft. (0.54 cu. m).

Adjustable : 15 in. (381 mm) sliding hopper. Auger dimensions : 12 in. (305 mm) diameter by 5.5 ft. (1.68 m) long for concrete. Auger drive : Hydraulic motor direct coupled to auger shaft. Auger speed : Up to 43 rpm.

Track dimensions : One track, 23 in. (584 mm) long, 8 in. (203 mm) wide, by 9 in. (229 mm) high. Track motor : 22.6 cid roller vane motor. Equipped with a track brake system. Wheel assemblies : Eight - 9 in. (229 mm) diameter by 3 in. (76 mm) wide wheels. Travel speed : Up to 40 fpm (12.2 mpm) paving, 93 fpm (28.3 mpm) auxiliary.

24 inches (610 mm) depending on mold profile.

Overall transport dimensions : 8.2 ft. (2.5 m) long, 7.3 ft. (2.23 m) wide, and 3.7 ft. (1.13 m) high to the top of the shroud.

3694 lbs. (1676 kg).

Track dimensions : 23 in. (584 mm) long, 8 in. (203 mm) wide, by 9 in. (229 mm) high. Track motor : 22.6 cid roller vane motor. Travel speed : Up to 40 fpm (12.2 mpm) paving, 93 fpm (28.3 mpm) auxiliary. Track load (rear) : 1225 lbs. (555.7 kg). Ground pressure at 22 psi. Track load (front) : 1275 lbs. (578.3 kg.), with weight evenly distributed on both tracks, ground pressure at 12 psi. Optional three-track overall dimensions : 9.5 ft. (2.9 m) long, 6.6 ft. (2.01 m) wide, and 3.5 ft. (1.07 m) high.
