Type : Kohler, air-cooled gasoline. Horsepower : 18 hp (13.4 kW) @ 3000 rpm. Electric Start : 12 volt start motor with a 25 amp regulator-rectifier.

Fuel Reservoir : Console 9 gal. (34 L), Carriage 9 gal. (34 L). Hydraulic Oil : Console 15.3 gal. (57.9 L), Carriage 9 gal. (34 L).

Self-Contained : Hydraulic console with easy-to-operate controls, including variable travel. Can be positioned in other locations on the main frame for operator safety and convenience. Carriage Drive : Designed for operator ease in controlling travel speed and direction of the carriage.

Traction Drive : Two drive and two idler bogies standard. Drive bogies include two hydraulically driven flanged wheels, 3.25 in. (83 mm) wide for 2 in. (51 mm) square tubing or cupped wheels to run on 2 in. (51 mm) pipe. Optional urethane wheels or urethane wheels with removable flanges. Traction Speed : Up to 31 fpm (9.4 mpm). Automatic Advance on C-750 : Electronically controlled at the end of the finishing pass. As machine advances, the undercarriage can change attack angle and concrete finishing resumes.

Frame Construction : All-welded steel, pin-connected, main frame, 16 ft. (4.88 m) to 120 ft. (36.58 m). Finishing width is normally 4 ft. (1.22 m) less than frame width indicated.

Extendible Frame for Finishing Widths : 4 ft. (1.22 m), 8 ft. (2.44 m), 12 ft. (3.66 m), or 16 ft. (4.88 m) increments. The C-750 assures a specified tolerance of one-eighth inch (3.2 mm) in 12 ft. (3.66 m). Includes a self-widening capability for use on tapered decks and slabs. Self-widens up to 12 ft. (3.66 m) as machine advances. A 360 degree turntable on the upper carriage allows maximum skewing of the undercarriage to keep the finishing cylinders parallel to the center of the slab.

Hydraulically operated for on-the-go crown elevation changes. Power transition adjusters can be installed at most pin-connected points.

Finishing Cylinders : Double-cylinder undercarriage with two reversible 10 in. (254 mm) diameter, 48 in. (1219 mm) long cylinders. Augers : Two augers, one 10 in. (254 mm) diameter (right-hand) and one 10 in. (254 mm) diameter (left-hand) with auger guard. Finishing Pan : 25 in. (635 mm) x 22 in. (559 mm) trailing float pan.

Type : Honda, air-cooled gasoline. Horsepower : 19 hp (14.1 kW) @ 3000 rpm. Electric Start : 12 volt start motor.

Engine (2) : Type : Yanmar diesel.


Power : 19.9 hp (14.8 kW) @ 3000 rpm. Power transition adjuster (PTA). Transport assembly includes four 12-ply tires and towing tongue for job site use only. Adjustable hydraulic, pan-type vibrator for latex overlay applications or with protruding fin for street work. Hydraulic, stinger-type vibrator and mount assembly, equipped with bent vibrator which rotates 180 degrees at the end of each pass, to allow vibration close to paving form. Incorporated cylinder lowering attachment for single-cylinder and double-cylinder. Hydraulic lowering attachment for single-cylinder and double-cylinder. Main frame extensions. Single-cylinder undercarriage, 10 in. (254 mm) diameter, 48 in. (1219 mm) long. Single-cylinder undercarriage, 10 in. (254 mm) diameter, 60 in. (1524 mm) long. Adjustable augers for double-cylinder, two 7.75 in. (197 mm) diameter double pitch augers with manual vertical adjustment. 60 in. (1524 mm) long by 10 in. (254 mm) diameter cylinder with external vibration for double-cylinder undercarriage and single-cylinder undercarriage. Double finishing pan assembly. Trimmer undercarriage assembly with trimmer wheel assembly for fine grading the subgrade. All bogie drive. Four hydraulically powered bogies. Third wheel assist bogies, consisting of four single wheel idler bogies and spreader beam to distribute machine weight. Spare console, upper and undercarriage assembly. Additional emergency stop buttons available. Other options are available to customize machine to accommodate applications and customer needs.
