Type : C7.1 Caterpillar turbocharged diesel engine. Emission Level : Tier 4 Final, Stage IV. Power : 302 hp (225 kW) @ 2200 rpm. 12.7 gph (48.1 Lph) @ 80% load.

Fuel reservoir : 160 gal. (606 L). Hydraulic oil reservoir : 230 gal. (871 L).

Type : Electronic-over-hydraulic. Controls : GOMACO’s exclusive G+ control system features self-diagnostics for grade and steering. It features multi-language, metric or imperial units, and a 6.5 in. (165 mm) anti-glare display screen. Control indicators : Color graphical performance indicators allow operator to monitor control signals for machine guidance on stringline or 3D.

Telescoping : Dual-telescoping frame telescopes up to 7 ft. (2.13 m) on each side for a total of 14 ft. (4.27 m) of telescoping capabilities.

Type : Hydraulically powered dual-drive, reversible 20 in. (508 mm) diameter. Auger speed : Variable up to 85 rpm.

24 ft. (7.32 m) wide : One 4 ft. (1.22 m) right-hand drive section, one 4 ft. (1.22 m) left-hand drive section, and one 4 ft. (1.22 m) power transition adjuster (PTA) section. Balance of inserts per customer specifications. Additional insert sections available for spreading widths up to 36 ft. (10.97 m). Hydraulically pressure-compensated sideplates with adjustment up to 19 in. (483 mm). International : A 7.5 meter wide strike-off is available for countries using the metric system.

Width : 5 ft. (1.52 m). Length : 22 ft. (6.71 m). Fold height : 14.6 ft. (4.45 m). Hinge system : Two 3.5 in. (89 mm) by 30 in. (762 mm) hydraulic cylinders. Hinge fold speed : 8 seconds up and 6 seconds down. Belt drive : Hydrostatic. Belt speed : Variable speed control up to 491.5 fpm (149.81 mpm). Belt tensioning : Pressure-compensated hydraulic belt tensioning for varying haul road height. Conveyor assembly system : Mounts on either side of machine. Hydraulic conveyor deflector : Directs the flow of concrete at discharge end of conveyor. Optional : 3 ft. (.91 m) conveyor inserts for variable spreading widths of 26 ft. (7.92 m) and wider.

Type : Two hydraulically powered, gear-driven crawler tracks. Overall track length : Series 6 tracks, 12 ft. (3.66 m). Track pad width : 15.75 in. (400 mm). Track speed : Variable up to 28 fpm (8.53 mpm) paving, and auxiliary up to 85 fpm (25.91 mpm). Ground pressure : 23 psi based on 79,000 lbs. (35,834 kg) machine with mold and weight evenly distributed. Leg height adjustment : 36 in. (914 mm) hydraulic adjustment and manual adjustment of 11.75 in. (298 mm) for a total height adjustment of 47.75 in. (1213 mm).

Placing/spreading width : 12 ft. (3.66 m) to 26 ft. (7.92 m) with no inserts needed for frame. Optional width of up to 36 ft. (10.97 m) with additional frame inserts. Operational length : 23.4 ft. (7.13 m). Operational width : 40.9 ft. (12.47 m) with 24 ft. (7.32 m) strike-off and conveyor belt down. Operational height : 13.3 ft. (4.05 m) with the mold extended 10 in. (254 mm) and legs extended 24 in. (610 mm) for placing and spreading material for an 8 in. (203 mm) slab. Minimum transport length : 29.7 ft. (9.05 m) with 24 ft. (7.32 m) strike-off attached. Minimum transport width : 12.1 ft. (3.69 m). Minimum transport height : 10.4 ft. (3.17 m) without strike-off or 10.9 ft. (3.32 m) with 24 ft. (7.32 m) strike-off attached.

Transport weight : 52,000 lbs. (23,587 kg) without strike-off mold and conveyor. Operational weight : 79,000 lbs. (35,834 kg) with 24 ft. (7.32 m) strike-off mold and conveyor. Note : Transport and operational weights and dimensions are variable, depending on machine options.

Four-corner outrigger system, manual operation or hydraulically powered. High-pressure or low-pressure water system. Frame extensions. Conveyor inserts. Strike-off inserts. 18 in. (457 mm) conveyor hopper extension. 3D package for stringless control. Other options are available to customize machine to accommodate applications and customer needs.
