Consult for options available.

Fuel tank reservoir : 30 gal. (113.6 L). Hydraulic oil reservoir : 50 gal. (189.3 L).

Type : Electronic-over-hydraulic. Controls : GOMACO’s exclusive G+ control system features forward and reverse steering and grade control. It is sensored via stringline or other methods from our sensor library. This provides ease of operation and accuracy in texturing and curing.

Track length : 5.2 ft (1.58 m). Center-to-center sprocket and idler distance of 3.4 ft. (1.04 m). Track width : 11.8 in. (300 mm). Track speed : Low-range track speed up to 36 fpm (11 mpm) and a high-range track speed up to 96 fpm (29 mpm). Hydraulic leg height adjustment : 36 in. (914 mm). Ground pressure : 19.34 psi based on 36,920 lb. (16,747 kg) machine weight.

Transport width : 9.8 ft. (2.99 m) with spray bar folded and transverse tining broom removed. Transport height : 10.4 ft. (3.17 m) with the exhaust pipe removed.

Operating weight : 36,920 lbs. (16,747 kg) based on the machine texturing/curing a 24 ft. (7.32 m) slab. Note : Transport and operational weights and dimensions are variable, depending on the number of machine options.

Insert lengths available are 4 ft. (1.22 m), 8 ft. (2.44 m), and 12 ft. (3.66 m).

Spraying pump (max) : 29.18 gpm (110.46 lpm). Cure tank reservoir : 300 gal. (1135.6 L).

1.) Longitudinal tining. 2.) Transverse tining : 10 ft. (3.05 m) wide with 5 in. (127 mm) long wire tines spaced to meet specification requirements. 3.) Single pass transverse texture/cure option : 7 ft. (2.13 m) transverse tining bar with a 7 ft. (2.13 m) folding spray bar. Optional : Additional wire tine texturing members are built to specifications.

Burlap drag. Burlap water system. Poly-roll attachment. Dual cure spray bar. Skewed tining. Longitudinal tining. Transverse spray bar. G+ sensor library. Poly track pads. Hot water tank.
