Type : CAT diesel. Power : 50 hp (37.3 kW) @ 2800 rpm.

Fuel reservoir : 33 gal. (124.9 L). Hydraulic oil reservoir : 57 gal. (215.8 L).

Self-contained : Hydraulic console with easy-to-operate controls.

C-650-S traction drive : Two gear-driven crawler tracks, hydraulically powered, 11 ft. (3.35 m) long; center-to-center sprocket/idler length, 9 ft. 4 in. (2.84 m). Track pad width : 11.8 in. (300 mm). Operating speed : Variable up to 20.5 fpm (6.25 mpm). C-650-F traction drive : Two hydraulically driven bogies and two idler bogies with 3.25 in. (83 mm) wide double-flanged bogie wheels. Operating speed : Variable up to 32.6 fpm (9.94 mpm).

Frame : All-welded steel, pin-connected main frame.

Two 10 in. (254 mm) x 15 in. (381 mm) 12-ply tires and removable towing tongue for job site use only.

24 ft. (7.32 m) to 56 ft. (17.07 m). Consult factory for narrower widths. Adjustable frame width : The frame is adjustable with extensions in 2 ft. (.61 m), 4 ft. (1.22 m), 8 ft. (2.44 m), or 12 ft. (3.66 m) increments.

Finishing width : The normal finishing width is 5 ft. (1.52 m) less than frame width indicated. Finishing widths are from 19 ft. (5.79 m) to 51 ft. (15.54 m).

One set of slipform assemblies, depth to customer specifications.

Finishing cylinder : Two 10 in. (254 mm) diameter, 48 in. (1219 mm) long. Cylinder rotation : 353 rpm. Carriage speed : Variable to 164 fpm (50 mpm). Augers : One 10 in. (254 mm) diameter (right-hand) and one 10 in. (254 mm) diameter (left-hand) with auger guard. Finishing pan : 25 in. (635 mm) x 22 in. (559 mm) trailing float pan.

Hydraulically operated : for on-the-go grade elevation changes. Power transition adjusters can be installed at pin-connected points.

Two lines of adjustable 1000 series Spanit® work bridge. One Spanit is positioned directly behind the finisher and used as a cross-walk and for hand finishing. The other Spanit is positioned further behind the machine and serves as a form tie and can be used for a burlap drag support.

24 ft. (7.32 m) unit : C-650-S @ 12,620 lbs. (5,724.4 kg); C-650-F @ 9,100 lbs. (4,127.8 kg). Frame extensions : 12 ft. (3.66 m) @ 750 lbs. (340 kg); 8 ft. (2.44 m) @ 525 lbs. (238.1 kg); 4 ft. (1.22 m) @ 300 lbs. (136.1 kg); and 2 ft. (.61 m) @ 150 lbs. (68 kg).

Hydraulic pan-type vibrator for latex overlay applications or with protruding fin for street work. Hydraulic, stinger-type vibrator and mount assembly, equipped with bent vibrator which rotates 180 degrees at the end of each pass, to allow vibration close to paving form. Cylinder lowering attachment. Main frame extensions. Seat assembly. Vibrating single and double 60 in. (1,524 mm) cylinders. Automated steering and/or grade control system (C-650-S). Automated grade control system only (C-650-F). Spare parts kit and sensor line kit. Other options are available to customize machine to accommodate applications and customer needs.
