Type : CAT diesel. Power : 50 hp (37.3 kW) @ 2800 rpm.

Fuel reservoir : 33 gal. (124.9 L). Hydraulic oil reservoir : 57 gal. (215.8 L).

Self-contained : Hydraulic console with easy-to-operate controls.

SL-650-S traction drive : Two gear-driven crawler tracks, hydraulically powered, 11 ft. (3.35 m) long; center-to-center sprocket/idler length, 9 ft. 4 in. (2.84 m). Track pad width : 11.8 in. (300 mm). Operating speed : Variable up to 20.5 fpm (6.25 mpm). SL-650-F traction drive : Two hydraulically driven bogies and two idler bogies with 3.25 in. (83 mm) wide double-flanged bogie wheels. Operating speed : Variable up to 32.6 fpm (9.94 mpm).

Frame : All-welded steel, pin-connected main frame.

24 ft. (7.32 m) to 56 ft. (17.07 m). Consult factory for other widths. Adjustable frame width : The frame is adjustable with extensions in 2 ft. (.61 m), 4 ft. (1.22 m), 8 ft. (2.44 m), or 12 ft. (3.66 m) increments.

Finishing width : The normal finishing width is 5 ft. (1.52 m) less than frame width indicated. Finishing widths are from 19 ft. (5.79 m) to 51 ft. (15.54 m).

One set of slipform assemblies, depth to customer specifications.

Finishing cylinder : One 10 in. (254 mm) diameter, 48 in. (1219 mm) long. Cylinder rotation : 353 rpm. Carriage speed : Variable to 50 fpm (15.24 mpm). Augers : One 10 in. (254 mm) diameter (right-hand) and one 10 in. (254 mm) diameter (left-hand) with auger guard. Finishing pan : 25 in. (635 mm) x 22 in. (559 mm) trailing float pan.

Two lines of adjustable 1000 series Spanit® work bridge. One Spanit is positioned directly behind the finisher and used as a cross-walk and for hand finishing. The other Spanit is positioned further behind the machine and serves as a form tie and can be used for a burlap drag support.

24 ft. (7.32 m) unit : C-650-S @ 12,620 lbs. (5,724.4 kg); C-650-F @ 9,100 lbs. (4,127.8 kg). Frame extensions : 12 ft. (3.66 m) @ 750 lbs. (340 kg); 8 ft. (2.44 m) @ 525 lbs. (238.1 kg); 4 ft. (1.22 m) @ 300 lbs. (136.1 kg); and 2 ft. (.61 m) @ 150 lbs. (68 kg).

Main frame extensions. Seat assembly. Vibrating single and double 60 in. (1524 mm) cylinders. Automated steering and/or grade control system (SL-650-S). Automated grade control system only (SL-650-F). Spare parts kit and sensor line kit. Other options are available to customize machine to accommodate applications and customer needs.
